In today’s rapidly evolving IT landscape, maintaining reliable, high-performing infrastructure is crucial for success. Whether you’re running a small application or managing complex distributed systems, effective monitoring helps you identify and resolve issues before they impact your users. Prometheus and Grafana are two of the most powerful open-source tools for infrastructure monitoring, providing a robust and scalable solution to collect, analyze, and visualize metrics.



In this blog, we’ll walk through the steps to set up Prometheus and Grafana, explore their architecture and components, and share best practices for effective monitoring in production environments.



Key Takeaways

• Comprehensive Monitoring: Prometheus and Grafana offer a scalable solution to monitor metrics across various systems, enhancing visibility and system health.
• Customizability: From customizable dashboards to a wide array of exporters, these tools can be tailored to monitor almost any infrastructure component.
• Proactive Alerting: With built-in alerting capabilities, you can configure real-time notifications to tackle issues before they escalate.
• Open-Source and Extensible: Both tools are open-source, supported by an active community, and extensible via plugins and custom exporters, making them highly adaptable.



What Are Prometheus and Grafana?



Before diving into the setup process, let’s briefly cover what Prometheus and Grafana are and why they are so popular in the DevOps community.



Prometheus



Prometheus is an open-source monitoring and alerting toolkit originally developed by SoundCloud. It specializes in collecting and storing time-series data, making it ideal for monitoring metrics such as CPU usage, memory consumption, and response times.



Architecture:







Prometheus works by scraping metrics from configured endpoints, known as exporters. Its components include:

• Prometheus Server: Scrapes and stores metrics.
• Client Libraries: Available for Go, Python, Java, and Ruby to help instrument custom applications.
• Alertmanager: Manages alert notifications based on Prometheus queries.
• Push Gateway: Allows short-lived jobs to expose their metrics.
• PromQL: Prometheus Query Language, used to retrieve and aggregate data.



Key Features:



• Time-series database (TSDB) optimized for monitoring
• Multidimensional data model using labels
• Powerful query language (PromQL)
• Alerting and rule-based notifications
• Scalable architecture with support for federation



Grafana



Grafana is an open-source platform for data visualization and monitoring. It integrates seamlessly with Prometheus and many other data sources to create beautiful and informative dashboards. Grafana helps turn raw metrics into insightful graphs, helping teams visualize trends, diagnose issues, and share reports across teams.



Architecture:



Grafana’s backend is built in Go, serving APIs and managing data source connections, while the frontend, built with TypeScript, offers a flexible UI. Key components include:

• Data Sources: Grafana supports multiple data sources beyond Prometheus, such as InfluxDB and Elasticsearch.
• Plugin System: Extends Grafana’s functionality with plugins for new visualizations, data sources, or applications.



Key Features:



• Multi-source data visualization
• Real-time monitoring and alerting
• Customizable dashboards with rich visualization options
• User authentication and role-based access control
• Plugin system for extending functionality



Setting Up Prometheus



Let’s start by setting up Prometheus to collect metrics. For this example, we will assume that you’re running Prometheus on a Ubuntu Linux server, though it can also be installed on other platforms like Windows or macOS.



Step 1: Download and Install Prometheus

• Download Prometheus from the official download page.
• Extract the Prometheus archive:

tar -xvzf prometheus-*.tar.gz
cd prometheus-*

• Move the Prometheus binary files to a standard location:

sudo mv prometheus /usr/local/bin/
sudo mv promtool /usr/local/bin/



Step 2: Configure Prometheus

• Open the default Prometheus configuration file prometheus.yml in a text editor:

sudo mv prometheus /usr/local/bin/
sudo mv promtool /usr/local/bin/

• Edit the prometheus.yml configuration file to define your metrics targets. A target is any endpoint that Prometheus will scrape for metrics. Here’s a simple configuration:

global:
scrape_interval: 15s
evaluation_interval: 15s

scrape_configs:
– job_name: ‘node_exporter’
static_configs:
– targets: [‘localhost:9100’]

Here, we’re using the Node Exporter to monitor system metrics. You may add other exporters, such as MySQL or Blackbox, for broader monitoring.



Step 3: Start Prometheus

• Start Prometheus with the following command:

./prometheus --config.file=prometheus.yml



Access the Prometheus UI at http://localhost:9090 to explore active metrics and scrape targets.

Setting Up Exporters for Prometheus



Exporters are small programs essential for Prometheus as they expose metrics from various services or system components that it collects by scraping from these endpoints.



Popular Exporters:



• Node Exporter: Exposes system-level metrics such as CPU, memory, disk usage, and network stats.
• MySQL Exporter: Exposes MySQL server metrics.
• Blackbox Exporter: Probes HTTP, DNS, TCP endpoints for availability.

Download and install the Node Exporter by running the following commands:



wget
https://github.com/prometheus/node_exporter/releases/download/v1.0.1/
node_exporter-1.0.1.linux-amd64.tar.gz
tar xvfz node_exporter-1.0.1.linux-amd64.tar.gz
cd node_exporter-1.0.1.linux-amd64
./node_exporterl

To run the Node Exporter at startup, create a systemd service:



[Unit]
Description=Prometheus Node Exporter
After=network.target

[Service]
User=prometheus
ExecStart=/usr/local/bin/node_exporter

[Install]
WantedBy=default.target



Step 4: Enable Prometheus



Then enable and start the service.

sudo systemctl daemon-reload
sudo systemctl start node_exporter
sudo systemctl enable node_exporter



The Node Exporter will expose system metrics on http://localhost:9100/metrics. Ensure that Prometheus is configured to scrape this target.

Setting Up Grafana



With Prometheus up and running, the next step is to set up Grafana to visualize the metrics collected by Prometheus.



Step 5: Download and Install Grafana

• Start the Grafana service:

sudo apt-get install -y software-properties-common
sudo add-apt-repository "deb https://packages.grafana.com/oss/deb stable main"

sudo apt-get update
sudo apt-get install grafana

• Add the Grafana repository to your system’s package manager and install it:

sudo systemctl start grafana-server
sudo systemctl enable grafana-server



Step 6: Access Grafana



Once Grafana is running, you can access its web interface by navigating to http://localhost:3000. The default login credentials are:

• Username: admin
• Password: admin

Step 7: Configure Prometheus as a Data Source



• After logging into Grafana, click on the gear icon (⚙️) in the left sidebar and select Data Sources.
• Add a new data source, and choose Prometheus from the list.
• Configure the Prometheus data source by providing the URL of your Prometheus server (e.g., http://localhost:9090) and click Save & Test to verify the connection.





Creating Dashboards in Grafana



With Prometheus as a data source, you can now create custom dashboards to visualize the metrics. Grafana provides a wide range of visualizations, including graphs, gauges, heatmaps, and tables.



Step 8: Create a New Dashboard



• Click on the + icon in the left sidebar and select Create Dashboard.
• Add a new panel to the dashboard by selecting the type of visualization (e.g., Graph).
• In the Query section, use PromQL (Prometheus Query Language) to retrieve specific metrics. For example, to display CPU usage, you can use the query:

node_cpu_seconds_total{mode="idle"}

• Customize the graph’s appearance by adjusting the time range, thresholds, and alert rules.



Step 9: Set Up Alerts



Grafana’s alerting system helps you stay informed about critical issues. Configure alerts by navigating to the Alert tab in a panel editor, setting conditions, and defining notification channels. For example, when the CPU usage exceeds a certain threshold, it can notify you.

• In the panel editor, click on the Alert tab.
• Define an alert condition, such as:

node_cpu_seconds_total{mode="idle"} < 20}

• Configure the notification channel (e.g., email, Slack) where alerts should be sent.



Best Practices for Prometheus and Grafana



• Establish a Consistent Labeling Strategy: Labels are fundamental to Prometheus’ data organization. Establish a clear and consistent labeling strategy to make querying more efficient and metrics easier to understand.
• Implement Role-Based Access Control (RBAC) in Grafana: Control access to your dashboards and data by setting up user roles and permissions. This is particularly important in environments with multiple teams to ensure data privacy and security.
• Enable Data Retention Policies in Prometheus: Prometheus can accumulate significant data over time. Configure retention policies in the prometheus.yml file to avoid running out of storage and to ensure that only relevant metrics are kept for analysis.
• Monitor Prometheus Itself: Use Grafana to monitor Prometheus’ own metrics. This can help you keep track of Prometheus’ performance, such as its memory usage, query execution time, and scrape latency, ensuring your monitoring system remains healthy.
• Use Thanos or Remote Storage for Scalability: For larger deployments, consider using Thanos or other remote storage solutions to handle long-term storage and ensure Prometheus can scale horizontally across multiple instances.
• Leverage Synthetic Monitoring with Blackbox Exporter: Use synthetic monitoring to proactively check the availability and responsiveness of services. Blackbox Exporter can simulate user behavior and monitor endpoints like HTTP, DNS, and TCP, providing early detection of potential issues.
• Secure Your Monitoring Setup: Enable HTTPS for both Prometheus and Grafana to encrypt data in transit. Use a reverse proxy to add basic authentication and ensure that only authorized users can access these services. Also, restrict network access using firewalls to limit exposure.
• Back Up Grafana Dashboards and Configurations Regularly: Grafana dashboards are critical for data visualization. Regularly export and back up these configurations to prevent accidental data loss, especially before making significant changes or upgrades.
• Utilize Grafana Variables for Dynamic Dashboards: Grafana allows you to create variables, making dashboards more dynamic and reusable. For instance, use variables to filter by different environments or instances without needing separate dashboards.
• Test Alert Rules Thoroughly: Ensure that your alert conditions are accurate and don’t trigger unnecessary notifications. Test alert rules in a staging environment to verify they function as expected and review alert thresholds regularly to reflect any changes in your infrastructure or service levels.
• Use Grafana Annotations to Track Events: Grafana annotations allow you to mark significant events on your dashboards, like deployments or incidents. This helps correlate metrics with events, aiding in root cause analysis and providing context for historical data.
• Automate Exporter Deployment and Configuration: In larger environments, manually deploying and configuring exporters can be time-consuming. Use automation tools like Ansible, Puppet, or Chef to streamline the process, ensuring consistent configurations and reducing setup time.



By following these best practices, you’ll ensure a more resilient, secure, and scalable monitoring setup. Prometheus and Grafana will provide greater insights into your infrastructure, enabling you to make data-driven decisions and maintain optimal system performance.



Conclusion



Prometheus and Grafana offer a powerful, flexible, and open-source solution for infrastructure monitoring and visualization. By leveraging Prometheus for robust data collection and Grafana for insightful visualizations, you can proactively manage your system’s health and ensure high availability for your services.

Following best practices like consistent labeling, secure configurations, and scalable storage solutions will further enhance the effectiveness and reliability of your monitoring setup. With the right approach, these tools empower teams to make informed decisions, quickly address issues, and continuously improve system performance. By implementing Prometheus and Grafana, you’re taking a significant step toward building a resilient and data-driven infrastructure, setting the stage for long-term success.
